Jakarta-Bandung High-Speed Railway No. 4 Yard

Featured Project Completed

Jakarta-Bandung High-Speed Railway No. 4 Yard

West Java, Indonesia

450T (900T Tandem) Max Capacity

GB / FEM Standard

Start Your Project

The Challenge

Frequent lifting of 900t girders required perfect synchronization between two gantry cranes to prevent structural stress.

Our Solution

Two 450t Beam Lifting Gantry Cranes equipped with PLC Tandem Synchronization for safe and stable lifting.

Project Specifications

Specification	Value
Yard Capacity	2,500 girders
Span of Gantry	35 m
Lifting Height	12 m
Girder Type	32m HSR Box Girder

Key Results

Tandem lifting sync error: <5mm

24/7 heavy-duty operation (Working Class A5)

Zero girder damage during loading
